AB 1746SC-IN04VI – Industrial Control Module

Description

Place of Origin:USA

Manufacturer:Allen Bradley

Model Number:1746SC-IN04VI

Number of Channels:4

Common Mode Voltage Range:-20 to 20 V

Absolute Input Voltage:±7.5 VDC or ±7.5 VAC RMS (Max)

Input Range:-10 to 10 VDC – 1 LSB

Absolute Input Current:-30 to 30 mA (Max)

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Current Rating:Backplane Current Draw: 35 mA at 5 V, 85 mA at 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

    The Allen Bradley 1746SC-IN04VI is engineered to deliver exceptional accuracy and reliability in industrial automation systems, making it ideal for applications requiring precise signal measurement.

    This module features a compact design that allows for easy integration into existing control systems, ensuring seamless operation in diverse industrial settings.

    Equipped with robust isolation technology, the 1746SC-IN04VI ensures protection against electrical interference, safeguarding critical data integrity during transmission.

    With a wide common mode voltage range and high-resolution input capability, this module is capable of handling a variety of signals from different sources, enhancing system versatility and compatibility.

    Designed with efficient power consumption in mind, the 1746SC-IN04VI minimizes energy usage without compromising performance, contributing to cost-effective and sustainable operations.
