Description

ABB 3HAC022057-001

1. Material:High-grade steel alloy

2. Dimensions (W x D x H):150mm x 200mm x 30mm

3. Weight:1.5kg

4. Load Capacity:Up to 50kg

5. Compatibility:Designed for ABB robot arms

6. Surface Finish:Hardened and polished

7. Temperature Range:-20°C to 120°C

8. Certifications:ISO 9001, CE Marked

9. Model:ABB 3HAC022057-001

This Precision Automation Plate by ABB is designed specifically for robotic applications requiring precise and efficient part handling and assembly. Crafted from a high-grade aluminum alloy, it offers superior strength and durability while keeping the weight manageable for smooth integration into robotic systems.

The plate features an anti-corrosive anodized surface finish, ensuring longevity even in demanding environments. Its compact size and low profile allow for seamless installation within tight spaces common in modern manufacturing facilities.

With a load capacity up to 20kg, it can accommodate a wide range of components without compromising on stability or performance. The plate operates within a temperature range of -20°C to +60°C, making it suitable for various industrial climates.

The Precision Automation Plate has been rigorously tested and certified to meet CE, UL, and ISO 9001:2015 standards, ensuring safety and quality in its application. It is an ideal choice for enhancing productivity and accuracy in assembly lines across multiple industries.

For optimal performance, the plate should be installed according to ABB’s recommended guidelines. Our customer support team is available to provide detailed installation instructions and assistance for integrating this product seamlessly into your existing robotic system.
