GE DS200DTBAG1A Circuit Board – Mark VI Control System Component

Description

Manufacturer:General Electric

Series:Mark VI

Part Number:DS200DTBAG1A

Functional Description:Digital Contact Terminal Card

Functional Acronym:DTBA

PCB Coating:Normal Coating

Assembly Type:Normal Assembly

Dimension:11 x 6 x 6.7 cm

Weight:0.14 kg

    The DS200DTBAG1A is a meticulously designed Digital Contact Terminal Board, tailored for critical operations within the GE Mark VI Turbine Control System. Its robust construction ensures long-lasting durability and exceptional reliability under varying industrial conditions.

    Featuring an innovative environmental protection paint on the printed circuit board (PCB), the DS200DTBAG1A is engineered to withstand harsh industrial environments, safeguarding against corrosion and ensuring uninterrupted performance.

    With a compact footprint of 100 x 70 x 20 mm and a lightweight design of just 0.25 kg, this board is easily integrated into existing systems without compromising space or operational efficiency. It is capable of handling up to 5 A at 24 VDC, providing ample power for demanding applications.

    Operating within the temperature range of -20°C to +60°C, the DS200DTBAG1A ensures stable performance across a wide spectrum of industrial climates. For storage, the device can endure temperatures as low as -40°C and as high as +85°C, further enhancing its versatility.

    Designed with precision engineering, the DS200DTBAG1A boasts a standard assembly type, making it compatible with a wide array of industrial control systems. Its ‘DTBA’ functional acronym signifies its capability in managing digital contacts efficiently, contributing to streamlined data processing and control functions.
