GE SR745-W2-P1-G1-HI-E-H, Industrial Transformer Management System

Description

Model Number:SR745-W2-P1-G1-HI-E-H

Brand:GE

Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz

Display Type:40 character Enhanced LCD

Dimensions:Height: 9 inches, Width: 7 inches, Depth: 7.125 inches

Keypad:Expanded for easier manual entry of setpoints

Winding Per Phase:2

Resistant Temperature Device (RTD) Type:3-wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum

Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA

Maximum Continuous Voltage Output:273 V

    The GE SR745-W2-P1-G1-HI-E-H is a robust and reliable solution for managing and protecting transformers, autotransformers, and reactors.

     With its advanced 40-character display and expanded keypad, this system allows for easy and precise manual entry of setpoints.

     The case dimensions are 9 inches high, 7 inches wide, and 7 ⅛ inches deep, making it compact yet sturdy.

     The transformer protection system can be conveniently mounted on a standard 19″ panel, ensuring a secure installation.

     The front of the case features multiple LEDs that provide real-time alerts for various statuses and errors, allowing operators to quickly identify and address any issues.

     Designed with safety and efficiency in mind, the GE SR745-W2-P1-G1-HI-E-H ensures seamless operation and optimal performance in demanding industrial environments.
