JL Electronics 4700MFD 400VDC/High Capacity Grid Forming & Grid Following Inverter, Power Conversion Module

Description

Operating Voltage Range:400VDC

Output Current Capacity:Variable

Regulation Accuracy:+/-0.5% of full scale

Efficiency:≥95%

Input Frequency Range:47-63Hz

Overload Protection:Built-in thermal and current limiting

Protection Rating:IP54

Weight:1.5kg

Dimensions:100mm x 120mm x 40mm

    The JL 4700MFD 400VDC / HCGF5 AS is engineered with cutting-edge technology, ensuring precise power management in demanding industrial environments. This high-performance module boasts a robust design capable of delivering exceptional efficiency and reliability.

    Featuring a wide operating frequency range from 20kHz to 60kHz, this module is suitable for a variety of applications requiring precise voltage regulation. Its output current capacity ranges from 10A to 100A, providing flexibility for different system requirements.

    With an efficiency rating of up to 98%, the JL 4700MFD 400VDC / HCGF5 AS minimizes energy loss, contributing to cost savings and environmental sustainability. The module’s regulation accuracy of ±0.5% ensures consistent performance under varying load conditions.

    Safety is paramount in industrial settings, which is why the JL 4700MFD 400VDC / HCGF5 AS comes equipped with advanced protection features. It safeguards against overvoltage, overcurrent, and short circuit events, ensuring system stability and longevity.

    For optimal thermal management, the module utilizes natural convection cooling, eliminating the need for complex cooling systems. This not only reduces maintenance costs but also simplifies installation and operation in confined spaces.
