NI SCXI-1126 High-Performance Signal Conditioning Module

Description

Brand:NI

Model:SCXI-1126

Module Type:Signal Conditioning Module

Input Channels:8

Input Range:+/-10V

Resolution:16-bit

Sampling Rate:100 kS/s

Operating Voltage:24 VDC

Certifications:CE, RoHS

Dimensions:100 mm x 100 mm x 25 mm

    The NI SCXI-1126 is a highly versatile signal conditioning module that enhances the accuracy and reliability of your measurement system. With its advanced design, it provides precise and stable signal conditioning for industrial automation environments.

    This module supports multiple input ranges, including ±10 V, ±5 V, ±1 V, and ±0.1 V, making it suitable for a wide range of applications. Its 24-bit resolution ensures high precision measurements, even in demanding test scenarios.

    The NI SCXI-1126 can handle sampling rates up to 250 kS/s per channel, enabling fast data acquisition and processing. The module’s high input impedance and excellent common mode rejection ratio (CMRR) of 110 dB ensure minimal noise interference, providing clean and reliable signals.

    Designed with robust engineering, this module features a compact form factor that integrates seamlessly into existing industrial control systems. The power supply requirement of 24 V DC makes it easy to deploy in various industrial settings.

    Built by National Instruments, a leading provider of test and measurement solutions, the NI SCXI-1126 is backed by extensive support and resources, ensuring reliable performance and longevity in your applications.
