Description
Product Type:Extended Temperature Converter
Power Supply:24 V DC (Power Rail)
Input Types:Thermocouple, RTD, Potentiometer or Voltage
Output:Current Output: 0/4 mA to 20 mA (Sink or Source Mode)
Configuration:Configurable via PACTware
Fault Detection:Line Fault (LFD) and Sensor Burnout
Safety Rating:Up to SIL 2 according to IEC 61508/IEC 61511
Rated Voltage:20 … 30 V DC
Mounting:On 35 mm DIN mounting rail according to EN 60715:2001
Dimensions:20 x 119 x 115 mm
Mass:Approximately 130 g
The Pepperl+Fuchs KFD2-UT2-EX1 is designed with an integrated 1-channel isolated barrier, ensuring high-level signal isolation and protection against external electrical disturbances.
Featuring a compact and robust design, this universal temperature converter offers a versatile solution for various industrial environments, supporting diverse input types including thermocouples, resistance temperature detectors (RTDs), potentiometers, and voltage inputs.
With configurable options accessible through PACTware, users can tailor the device’s performance to meet specific application requirements, enhancing system flexibility and efficiency.
The device includes advanced fault detection capabilities, including line fault (LFD) and sensor burnout detection, which helps maintain operational integrity and safety in critical control systems.
Certified up to SIL 2 according to IEC 61508/IEC 61511, the KFD2-UT2-EX1 meets stringent safety standards for functional safety applications, ensuring reliable performance in hazardous environments.
Compact yet powerful, this temperature converter seamlessly integrates into existing control systems, offering enhanced accuracy and reliability for a wide array of industrial applications.
