Tektronix 5A22N Arbitrary Function Generator

Description

Frequency Range:up to 20 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary

Resolution:14-bit vertical resolution

Sampling Rate:100 MSa/s

Output Channels:2 channels

Output Amplitude:2 Vpp

Output Impedance:50 ohms

Built-in Functions:Arbitrary waveform generation, frequency sweep, burst mode

    The Tektronix 5A22N Arbitrary Waveform Generator is a cutting-edge solution designed for professionals requiring precise waveform generation. With its high-frequency range of up to 50 MHz, it can produce a wide variety of waveforms for testing and simulation purposes. The generator boasts a waveform memory depth of 16 kpts, ensuring detailed and accurate signal representation. With a resolution of 14 bits, it delivers exceptional precision, making it ideal for demanding applications. The output amplitude ranges from +/-10 Vpp, providing ample power for a wide range of devices. The phase resolution is finely tuned to 0.088 degrees, allowing for highly accurate phase control. Featuring two channels, this generator supports synchronized operations for dual-channel testing scenarios. Its robust design ensures reliable performance even under continuous use, making it an indispensable tool for any engineering lab or test facility.
